APPLICATIONS
Blowtech Dust Extractors have wide applications in various machines/industries. Viz:
Surface Grinding / Tool & Cutter grinding Buffing machines Wood working machines Carbon dry powder collection Packaging machines etc.
ADVANTAGES
• Totally maintenance free
• High cleaning efficiency
• Continuous rating
• Compact design with a custom built hood
• Easy to operate
• Provides clean working condition thus increases the operator efficiency & prolongs equipment life
PRINCIPLE OF OPERATION
The dust generated is sucked by the air stream of suction blower through slit hood. The subsequent cloth filter retains the fine particles. The filtration system is based on fabric, suspended from a manual shaker mechanism to relieve filter clogging. Filtration can be provided as per application. Custom built designed hood can be provided to have optimum efficiency.
| Model | Units | DC-350 | DC-700 | DC-1200 | DC-1600 |
| Motor (3Ø) | (Hp./RPM) | 0.5 / 2880 | 2.0 / 2880 | 3.0/2880 | 5.0/2880 |
| Suction | (mmHg) | 200 | 400 | 500 | |
| Air flow | (m3 / hr) | 350 | 700 | 1250 | 1600 |
| Container capacity | (Litres) | 10 | 15 | 15 | 15 |
| Hose Diameter | (mm) | 60 | 60 | 60 | 75 |
| Weight | (@Kg) | 40 | 90 | 95 | 120 |
